About the PC-3000 SSD

Product Code: AP-ACE-PC3000 SSD
The PC-3000 SSD Software System operates in tandem with one of the three up-to-date hardware platforms – PC-3000 Express, PC-3000 UDMA, or PC-3000 Portable –1410880292-7905and it is intended for SSD repair and diagnosis and for data recovery from SSDs with SATA, PATA, mSATA, and M.2 (NGFF) interfaces and the capacity from 64 GB to 1 Tb produced by different manufacturers, such as OCZ, Corsair, Crucial, RunCore, A-DATA, G.Skill, Micron, Plextor, Intel, Samsung, SanDisk, Seagate, Kingston and others.

The PC-3000 SSD contains a set of specialized utilities for working with solid-state drives. This set includes the Universal Utility for diagnosing any SSD based on the ATA-8 specification (both currently existing models and those that will be manufactured in future) and the Active Utilities (Special Utilities) intended for working with a particular drive model in factory mode. It enables to deeply diagnose SSDs, to perform service operations, to re-write the drive’s microcode, to get direct access to memory chips, to carry out low-level formatting blocking the damaged cells and placing their addresses into the defect table, and to perform many other useful operations.

The PC-3000 SSD is started from the main window of the PC-3000 Express, UDMA, or Portable System by means of clicking a button on the desktop panel.


Data Recovery & Repair Functions

Functions for Data Recovery:

  • verify and restore the SSD’s service information
  • read and write the content of the SSD’s ROM
  • load the microcode into the drives’s RAM
  • emulate the translator operation in order to get access to user data
  • view the password and reset the password that was earlier set on an SSD
  • turn off background processes in an SSD to prevent data damage
  • provide direct access to the content of memory chips (it makes unsoldering unnecessary)
  • work with the Data Extractor

Functions for SSD Repair (to recover normal operation):

  • diagnose an SSD in factory mode
  • verify and restore the SSD’s service information
  • read and write the content of the SSD’s ROM
  • load the microcode into the drives’s RAM
  • view the logs of hidden defects (P-page, G-page)
  • perform low-level formatting to hide the discovered defects
  • change the configuration and identification parameters
  • reset the logs and S.M.A.R.T. parameters
  • search for the damaged memory chips

    Request a Quote

    Product Code:

    First Name:

    Last Name:



    Company Name:

    Shipping Address:



    Postal Code:

    Ask a Question

    Active Utilities

    The list of Active Utilities of the PC-3000 SSD System is expanded as soon as new SSD models are studied, and it is a continuous process. Those utilities that are currently available allow you to successfully recover data from all contemporary solid-state drives and to resolve the majority of wide-spread SSD problems. Special adapters and connectors have been added to diagnose and repair drives.

    SSD SATA-M.2 Adapter for PC-3000 Express/UDMA

    The new adapter is designated to connect SSD devices based on M.2 Key B or Key (B+M) interface to the PC-3000 ports. This type of drives uses a SATA interface in a small-sized M.2 form factor. The adapter has a 3.3 V power supply indicator and a drive activity indicator. It is compatible with single and double-sided modules, classes D1-D5, sized Type 2230, Type 2242, Type 2260, Type 2280.


    SSD SATA-mSATA Adapter for PC-3000 Express/UDMA

    The new adapter connects mSATA-interfaced SSD devices to the PC-3000 ports. This type of SSD has a SATA interface in a small-sized mSATA form factor. The adapter is equipped with a 3.3 V power supply indicator and a drive activity indicator. It is compatible with Full Size and Half Size modules.

    Delivery Package

    The PC3000 SSD Delivery package includes the following:

    • the System’s software, the resource database – 1 DVD
    • User manual – 1 book

    Delivery package options for the System:

    The PC-3000 SSD System can be operated via the PC-3000 Express, PC-3000 UDMA-E, or PC-3000 Portable controllers, so there are several delivery options:

    PC-3000 Express

    PC-3000 UDMA

    PC-3000 Portable

    Users of PC-3000 Express/UDMA/Portable can get quick online access to PC-3000 SSD

    There is no need to wait until the PC-3000 SSD is shipped when you have an urgent SSD recovery case from your important customer.
    The PC-3000 SSD software can be available immediately at the day of the payment.
    Since the payment is done you will find the following in the Customer Update Box:

    • the System’s software
    • the resource database
    • User manual
